* Single Ended
* Ver1 - U$490
* Ver2 - U$540
* Ver3 - U$530
Technical specifications:
- Output power: 12W x 2 (Ultra-linear)
- Frequency response: 20Hz - 28kHz
- Output impedance: 4, 8 Ohm
- THD: <= 1% (1kHz)
- Input sensitivity: 750mV
- Input impedance: 100k Ohm
- Size(WxDxH): 310x268x165 mm
- SNR: 88dB
- Preamp / driver tube: 6NJ2 x2
- Output tube: Shuguang (export version) EL34B x2, or PSVANE EL34
- Tube rectifier: 5Z4PJ x1
- Power transformer: 0.35mm lamination, EI96, 50mm stack
- Output transformer: 0.35mm audio use lamination (EI 66-36)
- Chassis: imported stainless steel mirror finish
- Stands - high speed diamond cut CNC aluminum
- Output: high quality binding posts
Features
- 6N2J preamp/driver stage.
- Shuguang EL34B output tube.
- Power transformer: 0.35mm SiFe lamination, properly aligned, multiple vacuum impregnated, for durability and noise free operation.
- Chassis - stainless steel, double layered design, no-minimal surface screws.
- Output transformer - heart of a tube amplifier, for high end edition, comes with transformer case with potting compounding for shielding, protection and look. Finishing - powder coated with wrinkle finish.
- Alps volume control.
- Standard version, PCB, power EI96x50, output EI66x36
- Point-to-point wiring version, enlarged output EI76x40, better bass, control, dynamics
- PCB version with enlarged output transformer EI76x40
 |
| Alps volume pot |
 |
| Stainless steel chassis, potted transformers, precision cut chassis, excellent suspension |
 |
| Input / output ports |
